DATA SHEET
SKY13306-313LF: GaAs SPDT Switch 100 MHz–6 GHz
Features
Functional Block Diagram
G
Broadband: 100 MHz – 6 GHz
G
G
G
G
Very low insertion loss: 0.5 dB typ. 2.4–2.5 GHz
High linearity: IIP3 = 53 dBm typ. 3 V
Low current consumption: <50uA @ 3 V
Miniature QFN-6 2 x 3 mm package
J 2
GND
J 3
1
2
3
6
5
4
V 1
J 1
V 2
G
Lead (Pb)-free and RoHS-compliant MSL1 @ 260 C per
JEDEC J-STD-020
Description
The SKY13306-313LF is an IC FET SPDT switch in a low-cost
miniature QFN- 6 plastic package. The SKY13306-313LF features
low insertion loss, excellent linearity and positive voltage operation
with very low DC power consumption. This general purpose switch
can be used in a variety of telecommunications applications, and
was designed for use as a transmit-receive switch for WLAN appli-
cations such as 802-11a/b/g. The QFN-6 package is lead (Pb)-free
and meets all current requirements for RoHS.
NEW
Skyworks offers lead (Pb)-free, RoHS (Restriction of
Hazardous Substances)-compliant packaging.
Product is in development stages, performance is based on simulation, and pin out and package are advanced and may change.
Skyworks Solutions, Inc. ? Phone [781] 376-3000 ? Fax [781] 376-3100 ? sales@skyworksinc.com ? www.skyworksinc.com
200745 Rev. C ? Skyworks Proprietary Information ? Products and Product Information are Subject to Change Without Notice. ? April 11, 2008
1
